Plate& type plate heat exchanger

Scope of Application

Chemical industry, petroleum chemical industry of natural gas, food,and medicine, power plants and other fields.

Full welding plate& plate heat exchanger is a new type heat exchanger,absorbing the advantages of removable plate heat exchanger make up for the deficiency of tube type heat exchanger.In the basis of semi-welding heat exchanger to complete remove gasket, could use in the occasion of middle pressure&temperature. It retains full countercurrent characteristics of removable heat exchanger compared to traditional shell and tube type heat exchanger with 3 to 5 times of high efficiency,depending on the application requirements,plate& type could be divided into three kinds,irremovable.Unilateral removable,double side removable.




Characteristic

Remains heat transfer characteristics of removable heat exchanger.

With low fouling coefficient.

Bearing high temperature.

Bearing high pressure.

Detachable.

No gasket aging,low operation cost.


Main specifications

Maximum processing capacity    2500m³/h

Maximum design pressure   35bar

Maximum temperature    350℃

Plate material    AISl304、316、316L、904L、Titanium、Hasetlloy、Ni、SMO254...


Reference map
